1. Operation
1-1 Nomenclature
Fig. 1-1
1
MOTOR LOADING
2
GEAR LOADING
3
SWITCH MODE
4
ARM TENSION
5
POLE BASE S
6
BRAKE SUB S ASS'Y
7
REEL S
8
GEAR PULLEY
9
DRUM
0
MOTOR CAPSTAN
A
GEAR CAPSTAN
B
ARM REVIEW
C
POLE BASE T
D
ARM PINCH ROLLER
E
GEAR IDLER
F
REEL T
G
HOLDER FPC SUB
H
BRAKE SOFT T
1
2
3
4
5
6
7
8
9
G
0
A
B
C
D
E
F
H
