Samsung Electronics3-12
Disassembly and Reassembly
3-3. Connector Diagram
Fig. 3-12 Connector Diagrams
NO. NO.CONNECTOR CONNECTORDIRECTION
DECK FPC CN501
DECK MAIN PCB
DRUM HEAD FPC CN101
CNP01 CNC01
CN602 CN471
CN702
CN802 MIC CONNECTOR
CNP02 LENS FPC
CN601
CN472 CNE01
CN603
CNV01
CN451
DECK MAIN PCB
MAIN PCB CCD PCB
MAIN PCB FUNCTION PCB
MAIN PCB FRONT PCB
FRONT PCB ASS’Y MIC
MAIN PCB ASS’Y LENS PCB
MAIN PCB REAR PCB
FUNCTION PCB ASS’Y EVF
MAIN PCB ASS’Y CVF
CN801
CNL102 B/L FPC
CNL101
CN604(CN606) HINGE FPC
CNL201
LCD FPC
HINGE FPC
LCD PCB B/L FPC
LCD PCB HINGE FPC
MAIN PCB HINGE FPC
LCD PCB LCD FPC
26
