3-1-4 Ass’y Case Left Removal

Samsung Electronics3-4

Disassembly and Reassembly

REMOVE 2 SCREWS.

REMOVE 3 SCREWS.

REMOVE 1 SCREW.

REMOVE THE ASS’Y-CASE LEFT

IN THE DIRECTION OF ARROW.

Fig. 3-4 Ass’y Case Left Removal
