Samsung Electronics 3-1

3. Disassembly and Reassembly

3-1. Cabinet and PCB

3-1-1 Ass’y Cover Housing Removal

REMOVE 2 SCREWS.

Remove the ass’y cover

housing in the direction

of arrow.

Fig. 3-1 Ass’y Cover Housing Removal
