Operation
1-4-6 Stop → REC
Set Camera mode.
Motor Loading rotates. Drum rotates.
Gear Wheel Motor, Gear Worm
Loading, Gear Loading, S/W
Mode, Gear Cam Main rotate.
Arm Tension moves in direction
of arrow by Mode Switch Cam
Curve.
Slider Main moves.
Pinch Roller attached to Motor
Capstan Shaft.
Lever Brake S detached from
Reel S by Slider Main.
Loading motor stops.Motor Capstan rotates.
Pinch Roller rotates.
Pinch Roller rotates.
Gear Capstan and Belt Timing,
Gear Pulley, Gear Idler rotates.
Reel T rotates.
Motor Capstan stops.
Reel T stops.
Push START/STOP key.
Motor Capstan rotates.
Reel T rotates. Reel S rotates.
Reel S stops.
Reel S rotates.
* Drum is still rotating during REC/PAUSE .
* Tape is wound to Reel T
by this operation.
