Samsung SCL770 - Ass’y Front Removal

174 pages

To Next Page

To Previous Page

Samsung Electronics 3-3

Disassembly and Reassembly

3-1-3 Ass’y Front Removal

REMOVE 1 SCREWS.

DISCONNECT THE HARNESS

FROM THE CN701 OF ASS’Y

MAIN PCB.

REMOVE THE ASS’Y FRONT IN

THE DIRECTION OF ARROW.

Fig.3-3 Ass’y Front Removal
