Samsung Electronics1-18
Operation
1-4-4 Stop → FF
Push FF key.
Drum rotates forward.Motor Loading rotates forward.
Gear Wheel Motor, Gear Worm
Loading ,Gear Loading, Switch
Mode, Gear Cam Main rotate.
Arm Tension moves in direction of
arrow by Switch Mode Cam Curve
to remove slack.
Slider Main moves in direction of
arrow.
Motor Loading stops.
Pinch Roller moves in direction of
arrow to put tape between Roller
and Capstan Shaft.
Lever Brake S and Brake Main T
released from Reel S and T by
Slider Main.
Pinch Roller rotates 19 times faster
than PLAY mode.
Reel T rotates 19 times faster
than PLAY mode.
Gear Capstan and Belt Timing,
Gear Pulley, Gear Idler rotate.
Motor Capstan rotates forward.
* This operation feeds tape 19 times faster than PLAY mode.
* Motor Capstan rotates 19 times faster than PLAY mode.
