Samsung SCL770 - Ass’y Case Top Removal

174 pages

To Next Page

To Previous Page

3-1-2 Ass’y Case Top Removal

Samsung Electronics3-2

Disassembly and Reassembly

REMOVE ASS’Y CASE TOP BY GENTLY RELEASING

1 LOCKING TAB WITH A SMALL SCREW DRIVER.

(SEE DETAIL "A")

REASSEMBLY : PUT THE 5 TABS INTO THE SLOTS,

WHILE SLIDING IT AS SHOWN IN DETAIL "B".

Fig. 4-2 Ass’y Case Top Removal
