Samsung Electronics 4-5
Alignment and Adjustment
000 00 01 02 03 ; 00=NTSC HI8, 01=NTSC NORMAL, 02=PAL HI8, 03= PAL NORMAL
001 C6 46 C6 46 ; DIS MODEL=“C6” , NON-DIS MODEL=“46”
46 46 NON-DIS MODEL=“46”, DIS MODEL=“C6” ,
002 67 - - - ; @IRIS CONTROL-LOW
003 A5 - - - ; @IRIS CONTROL-HIGH
004 70 - - - ; @P.CLK PWM-HIGH (ADCLK ;PAL HI8:14.250MHz, PAL-normal: 9.494800MHz NTSC:9.534964MHz)
005 08 - - - ; UPD16879 INIT 4th
006 44 - - - ; UPD16879 INIT 6th focus
007 44 - - - ; UPD16879 INIT 7th zoom
008 03 - - - ; CDS F-REG(f1,f0) CAM : BIT0:f0,BIT1:f1
009 B0 - - - ; CDS F-REG(f9,f2) CAM ;PGA GAIN -HIGH(0.00dB~ 30.0dB) CCD WHITE DEFECT DETECT AGC
00A 75 - - - ; CDS G-REG CAM ;DAC1 INPUT(HALL REFERENCE CONTROL;0V~3.0V)
00B 3D - - - ; CDS H-REG CAM ;DAC2 INPUT(HALL GAIN CONTROL;0V~3.0V)
00C 85 - - - ; CDS E-R(e1,e0),J-R(j0),M-R;D0:e0,D1:e1,D2:j0(CAM),D4:e0,D5:e1,D6:j0(VCR),D7:cds-rev=’1’
00D 50 - - - ; CDS F-REG(f9,f2) VCR COLOR ;PGA GAIN HI8 ME
00E 02 - - - ; CDS IC A REG AT VCR MODE
00F 1C - - - ; CDS TE-R (D0:T-R D9 set=’0’=offset=E-R,’1’=offset=#010(d0~d5: add111: d4~d9),D1:T-R
010 30 - - - ; CDS OFFSET (#00F: D0=’1’ OFFSET VALUE) d3,D2D3=C0C1(CAM), D4D5=C0C1(VTR)
011 00 00 01 01 ; VNTPAL2_H ccd vertical effective line
012 F7 F6 23 23 ; VNTPAL2_L ccd vertical effective line
013 01 00 01 00 ; HNTPAL2_H ccd horizental effective pixel
014 80 FF 78 FA ; HNTPAL2_L ccd horizental effective pixel
015 D2 D2 D2 2D ; PHG hg phase : DZOOM - EEPROM #296 CONTROL
016 01 - - - ; Mpoint_H mirror point h : MIRROR- EEPROM #336
017 74 - - - ; Mpoint_L mirror point h : MIRROR- EEPROM #337
018 A0 - D0 D0 ; AE TARGET-LOW BYTE (NON-DIS)
019 05 - 05 05 ; AE TARGET-HIGH BYTE (NON-DIS)
01A 70 - - - ; DIS AE TARGTE LOW
01B 0B 0B 0B 0B ; DIS AE TARGET HIGH
01C 80 - - - ; FLEX ZONE AE TARGET PERCENT( 80H= AUTO TARGET)
01D B0 B0 B0 88 ; SPOT LIGHT AE TARGET PERCENT( DIS: B0 , NON-DIS: 88)
01E 98 98 98 98 ; BLC ON AE TARGET PERCENT(DIS: 80 , NON-DIS: 77)
01F 98 98 98 98 ; SAND SNOW AE TARGET PERCENT( DIS: 90 , NON-DIS: 88)
020 60 - - - ; NEGA BLC AE TARGET PERCENT( 80H= AUTO TARGET)
021 08 05 - 05 ; AGC =#022 VALUE: #22F- H ENHANCER MIN
022 00 - - - ; AGC =#022 VALUE :#237- V ENHANCER MIN
023 E5 - - - ; AGC MAX % (E5=90%) FOR H,V ENHANCER MIN (#021,022)
024 80 - - - ; IRIS CONTROL GAIN ‘80’=CENTER
025 38 - - - ; SHUTTER START POINT OF IRIS CONTROL PERCENT(FF=100% IRIS OPEN)
026 A0 - - - ; AGC AETRGET PERCENT( =AETARGET*(#026/100hex)
CAMERA AUTO ADJUST MODE CONTENT
0DF A0 - - - ;EEPROM -TABLE -INITIAL (CAMERA ONLY:’99’+CONFIRM =EXCEPT(#061~#067,#680~#7FF),”
0CD FF - - - ;HALL AUTO ADJUST ‘AA’=ALL DATA INITIAL)
0CE FF - - - ;IRIS AUTO ADJUST
0CF FF - - - ;W/B AUTO ADJUST
0D0 FF - - - ;LENS AUTO ADJUST(WARNNING! DON°ØT’S USE WITHOUT AN INFINITE COLLIMATOR)
0D6 FF - - - ;ZOOM VR CENTER ADJT
0DB FF - - - ;AGC AUTO ADJUST(NORMALLY NOT USED)
0DE FF - - - ;3M LENS AUTO ADJUST AT SERVICE FIELD(DISTANCE :3M +/- 1Cm)
NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
“CAMERA ADJUST MODE, EEPROM ADDRESS SEQUENCE & DATA OF PAGE 0”
