NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
Samsung Electronics4-6
Alignment and Adjustment
027 90 - - - ; DIGITAL CLAMP CONTROL START AGC
028 A0 A0 A0 A0 ; CHROMA SUPPRESS PERCENT (00h=supress max,40h=25%,80h=50%)
029 48 - - - ; CHROMA SUPPRESS START AGC VALUE
02A 48 - - - ; NOISE SLICE START AGC VALUE
02B 80 - - - ; SHUTTER CONTROL GAIN ‘80’=CENTER
02C 80 - - - ; AGC CONTROL GAIN ‘80’=CENTER
02D 30 - 38 - ; DIS AE AVERAGE CUTTING AT AUTO MODE
02E 40 - 48 - ; DIS AE AVERAGE CUTTING AT SPLOTLIGHT MODE
02F 30 - 38 - ; DIS AE AVERAGE CUTTING AT FLEXZONE MODE
030 40 - - - ; CDS F-REG(f9,f2) VCR COLOR ;PGA GAIN HI8 MP,NORMAL
031 08 0B - 0B ; AGC H CORE LEVEL
032 08 0B - 0B ; AGC V CORE LEVEL
033 12 - - - ; AGC GAMMA
034 01 - 01 01 ; OUTDOOR(5100K) R-Y GAIN -HIGH OUTDOOR COLOR
035 10 23 3B 42 ; OUTDOOR(5100K) R-Y GAIN -LOW OUTDOOR COLOR
036 00 - 00 00 ; OUTDOOR(5100K) B-Y GAIN -HIGH OUTDOOR COLOR
037 A0 B4 E5 C8 ; OUTDOOR(5100K) B-Y GAIN -LOW OUTDOOR COLOR
038 01 - 01 01 ; OUTDOOR(5100K) R,Mg HUE -HIGH OUTDOOR COLOR
039 30 2A 50 48 ; OUTDOOR(5100K) R,Mg HUE -LOW OUTDOOR COLOR
03A 00 01 00 00 ; OUTDOOR(5100K) G, Cy HUE -HIGH OUTDOOR COLOR
03B 0A 2A 01 13 ; OUTDOOR(5100K) G, Cy HUE -LOW OUTDOOR COLOR
03C 01 - 01 01 ; OUTDOOR(5100K) B, Cy, Mg HUE -HIGH OUTDOOR COLOR
03D 52 2B 70 60 ; OUTDOOR(5100K) B, Cy, Mg HUE -LOW OUTDOOR COLOR
03E 01 - 01 01 ; OUTDOOR(5100K) Ye, G HUE -HIGH OUTDOOR COLOR
03F 2A 28 40 3B ; OUTDOOR(5100K) Ye, G HUE -LOW OUTDOOR COLOR
040 64 - - - ; WB DASH( WAITING TIME :UPPER 4BIT, SPEED:,LOWER 4BIT)
041 43 43 42 52 ; BTRK1X: R GAIN TRACKING CURVE
042 C6 - - - ; WBSPEED
043 A0 A0 AC AA ; RBCMAX0
044 9A 9A 95 95 ; MGCMAX0
045 3E 3E 3D 3E ; RBCMIN0
046 6A 6A 60 69 ; MGCMIN0
047 30 - - - ; RBRESP IGNORE AREA(R-B)
048 30 - - - ; MGRESP IGNORE AREA(Mg-G)
049 8E 8E 94 94 ; CW_LEV_BF B XIAS WHITE DETECT AREA INI. VALUE(5100K)
04A 94 94 9C 9A ; CW_LEV_GF G XIAS WHITE DETECT AREA INI. VALUE(5100K)
04B 20 20 1A 1A ; CW_LEV_RF R XIAS WHITE DETECT AREA INI. VALUE(5100K)
04C 00 - - - ; CW_LEV_MF M XIAS WHITE DETECT AREA INI. VALUE(5100K)
04D 08 - - - ; AWB_STAB AWB STABLEMODE COUNTER UPPER LIMIT
04E 00 - - - ; HIGH TEMPERTURE CONSIDERABLE RANGE CHANGE-RATE(R XIAS)
04F 80 - - 80 ; LIKEWARM/LIKECOOL
050 06 - - 06 ; R-B OFFSET DEC, INI- VALUE
051 05 - - 05 ; Mg-G OFFSET DEC INI- VALUE
052 40 - - - ; OUTS_RBN :HIGH TEMPERTURE CONSIDERABLE RANGE CHANGE-RATE(R XIAS)
053 0C - - - ; OUTS_MG :GREEN LIGHT SOURCE CONSIDERABLE RANGE CHANGE-RATE
054 48 - - - ; INS_RB :5100K COLOR TEMPERTURE AREA
055 37 - - - ; Y_LEV_L0 :LOW LUMINANCE WHITE DETECT AREA INI- VALUE (HIGH 4BIT,LOW 4BIT SEPERATE)
056 04 - - - ; AWB_hall_shutter HALL VALUE= INPUT HALL -(shutter/(80*#056))
057 48 - - - ; PKOUD_IRIS
058 20 - - - ; PKOUD_FAR: ZOOM TELE & FOCUS FAR(5.9M) (#057+#058) LESS THEN ,SRTAT DECREASE RANGE
059 FF - - - ; PKSHUT_RAT
05A 40 - - - ; PKOUD_AMIN
05B FF - - - ; Mg DIRECTION CONTROL LIMIT
05C C1 - - - ; mAWB_Pkoud_step: ]UPPER 4BIT(INCREASE SPEED),LOWER 4BIT (DECREASE SPEED)
