Samsung Electronics 1-25
Operation
Fig. 1-20
MOTOR LOADING
DRUM
ARM TENSION
LEVER BRAKE S
BRAKE SUB S
REEL S
GEAR LOADING
SWITCH MODE
GEAR CAM MAIN
LEVER CAM
CHASSIS SUB
POLE BASE T
ARM REVIEW
ARM PINCH ROLLER
GEAR IDLER
REEL T
BRAKE SOFT T
MOTOR CAPSTAN
GEAR CAPSTAN
SLIDER MAIN
GEAR PULLEY
