Samsung Electronics 5-3
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
001 6009-001287 SCREW-SPECIAL;SM45C,2,TH,+,M1.4,L3.9(3.2)
002 6001-001575 SCREW-MACHINE;PH,+,M1.4,L3.5,ZPC(BLK),SW
003 6001-001417 SCREW-MACHINE
401 AD97-04500A ASSY-COVER-REEL;SUS+ETC,DE-10,ASSY
402 AD97-04498A ASSY-IDLER;POM+ETC,DE-10,ASSY
403 AD97-04757A HOUSING-ASSY;-,-,-,-,-,-,-,DE-6
501 AD97-04440A ASSY-DRUM PAL;-,DE-10,PAL
600 AD97-04625A ASSY-SEMI DECK;DE-10
To Next Page
