Samsung Electronics 5-7
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
002 6001-001575 SCREW-MACHINE;PH,+,M1.4,L3.5,ZPC(BLK),SW
004 AC60-12112A SCREW-BH;-,WHT,L2,L2,BH,+,-,M1.4,WHT,-
006 AC60-10017A SCREW-MACHINE;-,-,FEFZY,SWCH1018,+,M1.7,
020 AC60-30017A WASHER-SLIT;ID 1,OD 2.6,T 0.4,POLYSLIDER
502 AD66-00141A GEAR-CAPSTAN;DE-10,PA(1724K),-,-,-,-,-,-
503 AD66-00142A GEAR-PULLEY;DE-10,DURACON M90-44,-,-,-,-
504 AC66-62001A BELT-TIMMING;-,L137 T0.4,-,-,-,-,-,-
505 AD66-00130A LEVER-CAM;DE-10,SUS430 CP,0.6,-,-,-,-,-
506 AD66-00140A GEAR-CAM MAIN;DE-10,ZYTEL 70G-43L,-,-,-,
507 AD97-04496A ASSY-SLIDE-MAIN;SECC+ETC,DE-10,ASSY
508 AD66-00131A LEVER-EJECT;DE-10,DURANEX #3300,-,-,-,-,
509 AD66-00139A GEAR-LOADING;DE-10,DURACON M90-44,-,-,-,
510 AD97-04504A ASSY-LOADING-MOTOR;MOTOR+TEC,DE-10,ASSY
511 AD97-04554A ASSY-CAPSTAN-MOTOR;-,DE-10,ASSY
511 AD97-04555A ASSY-CAPSTAN MOTOR;-,DE-10,ASSY
512 AD61-00950A HOLDER-FPC SUB;DE-10,POM,-,-,-,NATURAL,-
601 AD97-04495A ASSY-MAIN CHASSIS;DE-10
