Samsung Electronics 5-11
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
170 AD97-02643A ASSY-COVER HOUSING
180 AD97-04252A ASSY-CASE RIGHT;ASS'Y ALL
181 AD64-00694A CASE-RIGHT;ABS94HB HF0660I G3532 ALL
182 AD64-00424A BUTTON-REC/STOP;ABS94HB RED ALL
183 AD61-00905A HOLDER-POWER;POM BLK ALL
184 AD64-00695A KNOB-POWER;ABS94HB HF0660I G3532 ALL
185 AD64-00696A LOCKER-POWER;ABS94HB GREEN ALL
186 AD61-00214A BRACKET-GRIP BACK;SUS304 T0.8 ALL
187 AD59-00044A UNIT-BELT GRIP;LEATHER, BLK ALL
188 AD97-03191A ASSY-CAP HOOD;ASS'Y ALL
189 AD61-00906A PLATE-SPRING POWER ALL
190 AD61-00915A SPRING-LOCK POWER ALL
909 AD60-10509A SCREW-TAP PWH
