Samsung Electronics 5-13
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
230 AD64-00757A INLAY-DIGITAL;PVC SHEET ALL
281 AD07-00027A PVI LCD;NTSC ALL
282 AD97-02233A ASSY-BACK LIGHT;ASSY,M2, CASIO ALL
283 AD97-04458A ASSY-LCD BOARD;NTSC ALL
284 AD64-00758A CASE-LCD TOP;ABS 94 VO NTSC, EXP ALL
285 AD64-00464B CASE-LCD BOTTOM;ABS94VO NTSC (COLOR) ALL
286 AD63-00188F COVER-HINGE TOP;ABS 94HB, TITAN ALL
287 AD63-00190A COVER-HINGE BOTTOM;ABS 94HB ALL
288 AD64-00445A BUTTON-LCD LOCK;PC/ABS ALL
289 AD64-00446A BUTTON-LCD REVERSE;ABS 94HB ALL
290 AD61-00585A GUIDE-LCD LOCK;POM BLK ALL
291 AD61-12033A BRKT-NUT;SECC T0.8 ALL
292 AD61-00344A SPRING-LCD LOCK;SWPB ALL
293 AD61-00627A SPRING-LCD REVERSE;SUS304 WPB ALL
294 AD97-02487A ASSY-HINGE;ASSY ALL
913 AC60-10019A SCREW-MACHINE;M2X4 FZB ALL
914 AC60-10028A SCREW-MACHINE;M1.7X3 FZB ALL
915 AC60-10043A SCREW-TAPPING;TAP1.7X6 FZB ALL
916 AC60-12128A SCREW-TAPPING;TAP1.7X4 FEB ALL
917 6001-001291 SCREW-MACHIN;M1.7X4 FZB ALL
