Samsung Electronics 5-15
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
123 AD63-00065C COVER-LI BATTERY ALL
201 AD63-00315A COVER-LEFT(W4);ABS94HB HG0760 G6238,TITAN SCL700
AD63-00315B COVER-LEFT(W4);ABS94HB HG0760 G6238,TITAN SCL710
AD63-00315C COVER-LEFT(W4);ABS94HB HG0760 G6238,TITAN SCL750
AD63-00315D COVER-LEFT(W4);ABS94HB HG0760 G6238,TITAN SCL770
202 AD64-70085A BADGE-SAMSUNG(30);AL (30mm) ALL
203 AD64-00753A BUTTON-EASY(W4);ABS94HB NTR ALL
204 AD64-00427A BUTTON-FUNCTION(W2);ABS94HB HF0660I G3532 ALL
205 AD61-00600A HOLDER-LOCK EVF;POM BLK ALL
206 AD61-00594A RAIL-EVF;POM BLK ALL
207 AD61-00595A RAIL-LOCK;ABS 94HB BLK ALL
210 AD97-04405A ASSY-CASE LEFT(W4);W4-PJ, LIGHT(X) SCL710
AD97-04406A ASSY-CASE LEFT(W4);W4-PJ, LIGHT(O) SCL700/SCL750/SCL770
211 AD64-00751A CASE-LEFT(W4);W4-PJ, LIGHT(X) SCL710
AD64-00751B CASE-LEFT(W4);W4-PJ, LIGHT(O) SCL700/SCL750/SCL770
213 AD64-00706A BUTTON-TAPE EJECT;ABS94HB HF0660I G3532 ALL
214 AD64-00707A BUTTON-VCR;ABS94HB HF0660I G3532 ALL
215 AD64-00755A KNOB-DUMMY(W4);ABS94HB NTR ALL
216 AD64-00235B BUTTON-FUNCTION-A(M2);ABS94HB HF0660I G3532 ALL
217 AD64-00240C KNOB-DIAL MENU(M2);ABS94HB HF0660I G3532 ALL
218 AD69-00045A PAD-LCD;SILICON ALL
219 AD97-03290A ASSY-TRIPOD;PC G3532 ALL
222 AD73-10048A RUBBER-SPEAKER;RUBBER BLK ALL
224 AD97-04508A ASSY-FUNCTION B'D(W4) SCL700
AD97-04464A ASSY-FUNCTION BOARD SCL710/SCL750/SCL770
227 AD97-00244A ASSY-SPEAKER;SC-L315C, 2816S ALL
242 AD61-00581A BRACKET-HINGE
903 AC60-10020A SCREW-MACHINE(2X5);BLK ALL
905 AC60-10054A SCREW-TAPPING(2X6);W4-PJ ALL
905 AC60-10054A SCREW-TAPPING(2X6);BLK ALL
912 AC60-10073A SCREW -TAP PLAIN(2X6);W-PJ(CASE-L+ASSY-EVF) ALL
