Samsung Electronics 5-17
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
131 AD64-00693G CASE-FRONT;880X,MIC(X),USB(X),TITAN SCL700/SCL710
AD64-00693H CASE-FRONT;880X,MIC(O),USB(X),TITAN SCL750
AD64-00693J CASE-FRONT;880X,MIC(O),USB(O),TITAN SCL770
132 AD67-00157A LENS-HOOD(AL);AL ALL
133 AD67-00038C LENS-HOOD(22X);ABS 94HB BLK ALL
134 AD64-00697A MASK-LAMP;PC CLR SCL700/SCL750/SCL770
AD63-00299A COVER-DUMMY LAMP SCL710
135 AD67-00156A MIRROR-LAMP;NYLON66(5232G) SCL700/SCL750/SCL770
136 AD64-00698A WINDOW-REMOCON;PMMA TITANE ALL
138 AD97-04436A ASSY-MIC;ASS'Y ALL
142 AD97-04471A ASSY-FRONT BOARD;MIC(X),LIGHT(0),USB(X) SCL700
AD97-04472A ASSY-FRONT BOARD;MIC(O),LIGHT(O),USB(X) SCL750
AD97-04473A ASSY-FRONT BOARD;MIC(O),LIGHT(O),USB(O) SCL770
144 4713-001152 LAMP-PURE XENON;6V,500mA,3W
906 AC60-10061A SCREW-TAPPING(T2X5);BLK ALL
