Samsung Electronics 5-19
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
112 AD97-02879A ASSY-ZOOM LENS;22X ALL
113 AD97-04856A ASSY-CCD
114 AD61-00576A BRACKET-LENS(22X)-180;SUS304 T0.5(22X) ALL
115 AD63-62008A SPACER-CCD;SILICON (Hi8) ALL
116 AD29-92001F FILTER-OLP;OG-BF455
120 AD61-00222A CHASSIS-TOP
121 AD61-00904A CHASSIS-BOTTOM
125 AD92-00005A ASSY-PCB DECK FPC
128 AD97-04462A ASSY-ROTARY FPC ALL
250 AD64-00422A CASE-TOP;W-PJ,ABS94HB
500 AD97-04370A ASSY-DECK;DE-10 NTSC
905 AC60-10054A SCREW-TAPTITE(2X6);BLK ALL
907 AC60-10024A SCREW-MACHINE(2X3);YEL ALL
