Samsung Electronics 5-21
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
122 AD63-00064D COVER-JIG;W-PJ/D/GRAY,ABS94HB ALL
150 AD97-03188A ASSY-CASE REAR;ASS'Y:Hi8 (D.ZOOM)- SCL700/SCL710
AD97-02604A ASSY-CASE REAR;ASS'Y:Hi8 (S.SHOT) SCL750/SCL770
151 AD64-00418E CASE-REAR;Hi8 (D.ZOOM) SCL700/SCL710
AD64-00418C CASE-REAR;Hi8 (S.SHOT) SCL750/SCL770
152 AD61-00578A BRACKET-REAR(W2);SUS304 T0.8 1/2H ALL
153 AD64-00423A BUTTON-SNAP SHOT;ABS94HB HF0660I G3532 ALL
154 AD61-00573A HOLDER-BATTERY EJECT;ABS94HB HF0660I G3532 ALL
155 AD61-00574A HOLDER-SNAP SHOT;POM NTR ALL
156 AD64-00431A KNOB-BATTERY EJECT;ABS94HB HF0660I G3532 ALL
157 AD64-00432A KNOB-ZOOM;ABS94HB HF0660I G3532 ALL
158 AD61-00602A HOLDER-ZOOM;POM NTR ALL
160 AD64-00176B KNOB-DIDECTOR;ABS94HB HF0660I G3532 ALL
161 AD64-00182B LOCKER-BATTERY;POM BLK ALL
162 AD61-00218A SPRING-BATTERY EJECT;SUS 304 WPB ALL
163 AD61-00219A SPRING-BATTERY LOCK;SUS 304 WPB ALL
164 AD61-00220A SPRING-SNAP SHOT;SUS 304 WPB ALL
165 AD97-02894A ASSY-REAR B'D;ASSY(Hi8) ALL
220 AC61-32047A PLATE-NUT;SECC T0.8 ALL
906 AC60-10061A SCREW-TAPPING(T2X5);BLK ALL
