Samsung Electronics6-4
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
D602 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
D603 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
D901 0401-001097 DIODE-SWITCHING;HN2D01FU,80V,80mA,1-2T1C
D903 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
DP03 0405-001083 DIODE-VARACTOR;MA367,30V,10nA,SOD-323,TP
IC101 1201-001312 IC-PREAMP;CXA2032Q,QFP,32P,7.0MIL,SINGLE
IC201 1204-001759 IC-VIDEO PROCESS;UPC5020GS-129,SOP,24P,3
IC401 1204-001946 IC-OSD PROCESSOR;UPD6467GR,SSOP,20P,173M
IC451 AC14-12012T IC-OP AMP;TA75S01F(TE85L),QFP,-
IC501 0909-001013 IC-REAL TIME CLOCK;5C372,8BIT,SOP,8P,-,3
IC502 1003-001241 IC-MOTOR DRIVER;LB11990W,SQPF,64P,-,-,1A
IC601 AD09-00080A IC MICOM;uPD70F3040GM-UEU,W-PJ,176,2.7V
IC602 1203-002538 IC-VOLTAGE REGULATOR;XC6201P322MR,SOT-25
IC603 1103-001224 IC-EEPROM;524L50X51,2048x8Bit,SOP,8P,225
IC604 1203-002537 IC-VOL. DETECTOR;XC61FC2512MR,SOT-23,3P,
IC701 1201-001406 IC-AUDIO AMP;7458,SQFP,64P,393MIL,-,-,PL
IC901 1203-001534 IC-PWM CONTROLLER;TL1466I,QFP,64P,-,PLAS
IC902 1203-002522 IC-VOLTAGE REGULATOR;1572,SOT-25A,5P,2.9
ICA01 1002-001258 IC-A/D CONVERTER;AD9806JST80016R3,10BITS
ICL01 1201-001667 IC-OP AMP;12902,SSOP,TP,14P,173MIL,QUAD,
ICL02 1003-001200 IC-MOTOR DRIVER;UPD16835,SOP,38P,300MIL,
ICL03 AC14-12012T IC-OP AMP;TA75S01F(TE85L),QFP,-
ICP01 AD13-00010A IC-DSP;MB87L1551,W-PJ,176P,-,QFP,-,-,
ICP02 1003-001065 IC-CLOCK DRIVER;KS7221D,SOP,20P,225MIL,Q
ICV01 1204-001760 IC-VIDEO PROCESS;UPC5020GR-125,SOP,20P,3
ICV03 AD14-10001C IC-AMP;NJM2904V,SSOP,OP-AMP
L101 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L102 2703-000002 INDUCTOR-SMD;100uH,10%,2.5x3.2x2mm
L130 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L131 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm
L151 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm
L152 2703-000381 INDUCTOR-SMD;180uH,5%,3.2x2.5x2.2mm
L153 2703-000366 INDUCTOR-SMD;22uH,5%,2.5x2x1.8mm
L154 2703-000373 INDUCTOR-SMD;68uH,5%,2.5x2x1.8mm
L171 2703-000365 INDUCTOR-SMD;15uH,5%,2.5x2x1.8mm
L172 2703-000375 INDUCTOR-SMD;82uH,5%,2.5x2x1.8mm
L173 2703-000381 INDUCTOR-SMD;180uH,5%,3.2x2.5x2.2mm
L181 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L186 2703-000375 INDUCTOR-SMD;82uH,5%,2.5x2x1.8mm
L187 2703-000376 INDUCTOR-SMD;8.2uH,5%,2.5x2x1.8mm
L201 2703-000409 INDUCTOR-SMD;47uH,10%,3.2x2.5x2.2mm
L401 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L701 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
L702 2703-000002 INDUCTOR-SMD;100uH,10%,2.5x3.2x2mm
L902 2703-001871 INDUCTOR-SMD;10UH,20%,6X6X2.8MM
CP24 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP25 2203-001071 C-CERAMIC,CHIP;0.056nF,5%,50V,NP0,TP,160
CP26 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP27 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160
CP28 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP29 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP30 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP31 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP33 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP34 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP35 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP36 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP37 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP38 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP39 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP40 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP44 2203-001630 C-CERAMIC,CHIP;330nF,+80-20%,16V,Y5V,TP,
CP46 2203-001660 C-CERAMIC,CHIP;0.004NF,0.25PF,16V,NP0,TP
CP47 2203-002605 C-CERAMIC,CHIP;0.008nF,0.25pF,50V,NP0,TP
CP48 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP49 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
CP50 2203-000041 C-CERAMIC,CHIP;0.01nF,0.25pF,50V,NP0,TP,
CP51 2203-001660 C-CERAMIC,CHIP;0.004NF,0.25PF,16V,NP0,TP
CV01 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV02 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV03 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV04 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV05 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV06 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV07 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV08 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV09 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV10 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV11 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV12 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,-
CV13 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV14 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV15 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV18 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV20 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV21 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV22 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV23 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV26 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
D601 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
