Sanyo PLC-HF15000L Service Manual

Key No. Part No. Description Key No. Part No. Description
KL8-HF15000L00
Electrical Parts List
-272-
L4608 945 086 6037 IMPEDANCE,330 OHM P
L4609 945 086 6037 IMPEDANCE,330 OHM P
L4611 945 086 6037 IMPEDANCE,330 OHM P
L4612 945 086 6037 IMPEDANCE,330 OHM P
L4613 945 086 6037 IMPEDANCE,330 OHM P
L4614 945 086 6037 IMPEDANCE,330 OHM P
L4616 945 086 6037 IMPEDANCE,330 OHM P
L4617 945 086 6037 IMPEDANCE,330 OHM P
L4618 945 086 6037 IMPEDANCE,330 OHM P
L4623 945 086 6037 IMPEDANCE,330 OHM P
L4624 945 086 6037 IMPEDANCE,330 OHM P
L4626 945 086 6037 IMPEDANCE,330 OHM P
L5621 945 075 1388 INDUCTOR,10U M
L5622 945 049 1680 IMPEDANCE,60 OHM P
L5623 945 049 1680 IMPEDANCE,60 OHM P
L5624 945 049 1680 IMPEDANCE,60 OHM P
L5626 945 049 1680 IMPEDANCE,60 OHM P
L5627 945 049 1680 IMPEDANCE,60 OHM P
L5628 945 049 1680 IMPEDANCE,60 OHM P
L5629 945 049 1680 IMPEDANCE,60 OHM P
L5631 945 075 1388 INDUCTOR,10U M
L5632 945 049 1680 IMPEDANCE,60 OHM P
L5633 945 049 1680 IMPEDANCE,60 OHM P
L5634 945 049 1680 IMPEDANCE,60 OHM P
L5671 945 086 6037 IMPEDANCE,330 OHM P
L5672 945 086 6037 IMPEDANCE,330 OHM P
L5673 945 086 6037 IMPEDANCE,330 OHM P
L5674 945 086 6037 IMPEDANCE,330 OHM P
DIODE
D3601 307 223 5014 DIODE D1FM3
D3602 307 223 5014 DIODE D1FM3
D3606 307 223 5014 DIODE D1FM3
D3607 307 223 5014 DIODE D1FM3
D3621 307 223 5014 DIODE D1FM3
D3622 307 223 5014 DIODE D1FM3
D3641 307 223 5014 DIODE D1FM3
D3642 307 223 5014 DIODE D1FM3
D3651 307 254 4116 ZENER DIODE RSB6.8CS T2R
D4621 307 163 0414 DIODE 1SS352-(TPH3)
D4623 307 163 0414 DIODE 1SS352-(TPH3)
D4631 307 163 0414 DIODE 1SS352-(TPH3)
D4633 307 163 0414 DIODE 1SS352-(TPH3)
D4634 307 163 0414 DIODE 1SS352-(TPH3)
D4637 307 163 0414 DIODE 1SS352-(TPH3)
D4638 307 163 0414 DIODE 1SS352-(TPH3)
D4651 307 163 0414 DIODE 1SS352-(TPH3)
D4652 307 163 0414 DIODE 1SS352-(TPH3)
D4653 307 163 0414 DIODE 1SS352-(TPH3)
D4654 307 163 0414 DIODE 1SS352-(TPH3)
D4656 307 163 0414 DIODE 1SS352-(TPH3)
D4657 307 163 0414 DIODE 1SS352-(TPH3)
D4658 307 163 0414 DIODE 1SS352-(TPH3)
D4659 307 163 0414 DIODE 1SS352-(TPH3)
D4661 307 163 0414 DIODE 1SS352-(TPH3)
D5631 307 254 4116 ZENER DIODE RSB6.8CS T2R
AA8700 610 350 2816 ASSY,PWB,ID1 IF KL8A
RESISTOR
R8751 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8752 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8753 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8754 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8756 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
AA8710 610 350 2809 ASSY,PWB,ID2 IF KL8A
RESISTOR
R8757 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8758 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8759 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8761 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8762 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
AA8720 610 350 2830 ASSY,PWB,ID3 IF KL8A
RESISTOR
R8764 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8766 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8767 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8768 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8769 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
AA8730 610 350 2823 ASSY,PWB,ID4 IF KL8A
RESISTOR
R8771 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8772 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8773 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8774 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R8776 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
AA8740 610 350 2847 ASSY,PWB,BRIDGE KL8A
AA610 610 349 9451 ASSY,PWB,AC FILTER KL8A
CAPACITOR
! C604 304 073 4508 CERAMIC 2200P M 250V
! C606 304 073 4508 CERAMIC 2200P M 250V
! C607 304 073 4508 CERAMIC 2200P M 250V
! C608 304 073 4508 CERAMIC 2200P M 250V
! C618 304 073 4508 CERAMIC 2200P M 250V
! C619 304 073 4508 CERAMIC 2200P M 250V
! C621 304 094 3801 MT-POLYEST 0.22U K 275V
! C622 304 094 3801 MT-POLYEST 0.22U K 275V
! C623 304 094 3801 MT-POLYEST 0.22U K 275V
! C624 304 094 3801 MT-POLYEST 0.22U K 275V
! C626 304 094 3801 MT-POLYEST 0.22U K 275V
! C627 304 094 3801 MT-POLYEST 0.22U K 275V
! C628 304 094 3801 MT-POLYEST 0.22U K 275V
! C629 304 094 3801 MT-POLYEST 0.22U K 275V
RESISTOR
! R601 301 242 5314 MT-GLAZE 470K JA 1/2W
! R602 301 242 5314 MT-GLAZE 470K JA 1/2W
! R603 301 242 5314 MT-GLAZE 470K JA 1/2W
! R604 301 242 5314 MT-GLAZE 470K JA 1/2W
! R606 301 242 5314 MT-GLAZE 470K JA 1/2W
! R607 301 242 5314 MT-GLAZE 470K JA 1/2W
! R608 301 242 5314 MT-GLAZE 470K JA 1/2W
VARIABLE RESISTOR
! VA601 408 066 1700 VD TND14SE471KB0SLAA0
! VA602 408 066 1700 VD TND14SE471KB0SLAA0
! VA603 408 066 1700 VD TND14SE471KB0SLAA0
