Sanyo PLC-HF15000L Service Manual

Key No. Part No. Description Key No. Part No. Description
KL8-HF15000L00
-273-
Electrical Parts List
COIL
! L601 945 061 3990 LINE FILTER
! L602 945 061 3990 LINE FILTER
! L603 945 061 3990 LINE FILTER
! L604 945 061 3990 LINE FILTER
! L606 945 061 3990 LINE FILTER
MISCELLANEOUS
! F601 323 025 1204 FUSE 250V 8A
! F602 323 021 7804 FUSE 250V 6.3A
! F603 323 025 1204 FUSE 250V 8A
AA620 610 349 9468 ASSY,PWB,AC-DC POWER KL8A
TRANSISTOR
Q632 305 217 6600 TR 2SK3934
Q638 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q639 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q641 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q642 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q643 305 217 6600 TR 2SK3934
Q644 305 217 6600 TR 2SK3934
Q645 305 217 6600 TR 2SK3934
Q646 305 217 6600 TR 2SK3934
Q647 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q648 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q701 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q702 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC631 409 690 7918 IC FA5550N
IC632 409 702 9817 IC SSC9512S
IC633 409 702 9817 IC SSC9512S
IC634 409 692 2515 IC TA76L431FB
IC635 409 692 2515 IC TA76L431FB
CAPACITOR
! C631 304 094 3801 MT-POLYEST 0.22U K 275V
C633 303 222 1326 CERAMIC 1000P K 1K
303 271 9615 CERAMIC 1000P K 1K
C634 303 222 1326 CERAMIC 1000P K 1K
303 271 9615 CERAMIC 1000P K 1K
C635 303 260 1623 MT-POLYEST 1U J 400V
C636 303 260 1623 MT-POLYEST 1U J 400V
C637 404 123 4806 ELECT 390U M 420V
404 123 4905 ELECT 390U M 420V
C641 303 314 5918 CERAMIC 0.47U K 16V
C642 303 356 5112 CERAMIC 0.047U K 50V
C643 303 215 2214 CERAMIC 0.01U K 50V
C644 303 215 2214 CERAMIC 0.01U K 50V
C645 303 113 4112 CERAMIC 2200P K 50V
C646 303 397 7618 CERAMIC 1U K 25V
C647 303 215 2214 CERAMIC 0.01U K 50V
C649 303 367 0410 CERAMIC 0.1U K 50V
C651 303 356 5112 CERAMIC 0.047U K 50V
C653 303 398 5118 ELECT 33U M 25V
303 387 7116 ELECT 33U M 25V
C654 303 155 2213 CERAMIC 3300P K 50V
C655 403 460 5319 CERAMIC 1U K 50V
C656 303 157 3614 CERAMIC 100P J 50V
C657 303 157 6813 CERAMIC 680P K 50V
C658 303 367 0410 CERAMIC 0.1U K 50V
C659 303 367 0410 CERAMIC 0.1U K 50V
C661 403 367 5917 CERAMIC 100P K 1K
C662 403 481 6616 POLYPRO 0.056U J 630V
C664 403 269 1869 CERAMIC 470P K 1K
C665 403 469 6317 CERAMIC 0.47U K 50V
C666 403 480 3319 CERAMIC 10P D 1K
C667 403 480 3319 CERAMIC 10P D 1K
C668 303 367 0410 CERAMIC 0.1U K 50V
C669 303 367 0410 CERAMIC 0.1U K 50V
C671 303 356 5112 CERAMIC 0.047U K 50V
C672 303 403 2514 ELECT 220U M 35V
C673 303 398 5118 ELECT 33U M 25V
303 387 7116 ELECT 33U M 25V
C674 303 155 2213 CERAMIC 3300P K 50V
C675 403 460 5319 CERAMIC 1U K 50V
C676 303 157 3614 CERAMIC 100P J 50V
C677 303 157 6813 CERAMIC 680P K 50V
C681 403 367 5917 CERAMIC 100P K 1K
C682 403 481 6616 POLYPRO 0.056U J 630V
C684 403 269 1869 CERAMIC 470P K 1K
C685 403 469 6317 CERAMIC 0.47U K 50V
C686 403 480 3319 CERAMIC 10P D 1K
C687 403 480 3319 CERAMIC 10P D 1K
C691 403 480 3200 ELECT 1800U M 35V
C692 403 480 3200 ELECT 1800U M 35V
C693 303 417 9912 CERAMIC 4.7U K 25V
C694 303 215 2214 CERAMIC 0.01U K 50V
