Sanyo PLC-HF15000L Service Manual

-33-
Mechanical Disassembly
6 PFC-2 & Ballast-3/4 box removal
1 Remove 2 screws-A(T3x8) to remove the PFC Net 2 board.
2 Remove 3 screws-B(M3x6) to remove the shield case cover
3 Remove 4 screws-C(M4x6) to remove the PFC-2 & Ballast-3/4 box.
A
PFC-2 board
PFC Net 2 board
FN909
PFC-2 & Ballast-3/4 box
Ballast 4 board
Ballast 3 board
A
B
B
B
C
C
C
C
(M3x6)x2
(T3x8)x4
(M3x6)x4
(T3x8)x4
(M4x30)x4
Label side
(T3x8)x4
White connector
Black connector
White connector
Black connector
To: K36J
