Sanyo PLC-HF15000L Service Manual

-80-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
4 TBR <NSFILTERY**> / <NSFILTERUV**> 0 - 3 2
50 2:2 pull down setting
0 22 Film Mode Sensitivity Film Detection Sensitivity <FILMSTVT22> 0 - 15 2
51 2:3 pull down setting
0 Global Motion Sensitivity Film Detection Sensitivity <FILMSTVT23> 0 - 15 1
60 Sub Image
0 Center Contrast
Group
Composite / S-Video / Component / Digital /D-RGB-Video
/AnalogRGB / RGB-Video / HDCP-PC /HDCP-AV /SCART/ PJ-
Net
Value = (Menu Value - Menu Center) x Alpha / 10 + Center
(Effective Range)
Contrast [Max] 1023 [Min] 0
Brightness [Max] 1023 [Min] 0
Color [Max] 1023 [Min] 0
Tint [Max] 180 [Min] 0
Sharpness [Max] 57 [Min] 0 (Dummy)
WB R/G/B [Max] 1023 [Min] 0
BB R/G/B [Max] 1023 [Min] 0
Fixed Sharpness Up/Down [Max] 37 [Min] 0
0 - 1023
673/373/577/492/492/533/533/492/
492/533/492
1 Center Brightness 0 - 1023
512/512/512/512/512/512/
512/512/512/495/512
2 Center Color 0 - 1023
512/512/512/512/512/512/
512/512/512/495/512
3 Center Tint 0 - 180 90/90/90/90/90 /90/90/90/90/90/90
4 Fixed Sharpness(Up Scaling) 0 - 21 10/10/10/10/10/10/10/10/10/10/10
5 Fixed Sharpness(Down Scaling) 0 - 21 10/10/10/10/10/10/10/10/10/10/10
6 Center Sharpness(No FPGA) 0-37 16/16/16/16/16/16/16/16/16/16/16
7 Center WB Red 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
8 Center WB Green 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
9 Center WB Blue 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
10 Center BB Red 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
11 Center BB Green 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
12 Center BB Blue 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
13 Alpha Contrast 0 - 1000 60/60/60/60/60/60/60/60/60/60/60
14 Alpha Brightness 0 - 1000 90/90/90/90/90/90/90/90/90/90/90
15 Alpha Color 0 - 1000
140/140/140/140/140/140
/140/140/140/140/140
16 Alpha Tint 0 - 1000 10/10/10/10/10/10/10/10/10/10/10
17 Alpha Sharpness 0 - 1000 10/10/10/10/10/10/10/10/10/10/10
18 Alpha WB Red 0 - 1000 40/40/40/40/40/40/40/40 /40/40/40
19 Alpha WB Green 0 - 1000 40/40/40/40/40/40/40/40 /40/40/40
20 Alpha WB Blue 0 - 1000 40/40/40/40/40/40/40/40 /40/40/40
21 Alpha BB Red 0 - 1000 20/20/20/20/20/20/20/20/20/20/20
22 Alpha BB Green 0 - 1000 20/20/20/20/20/20/20/20/20/20/20
23 Alpha BB Blue 0 - 1000 20/20/20/20/20/20/20/20/20/20/20
80 FINE FPGA - Setting
0 UV_DLT 0 - 31 3
1 UV_GAIN 0 - 2047 1030
2 UV_SFT 0 - 32767 6180
3 Demo On/Off Demo Mode On/Off (1:ON,0:Off) 0 - 1 0
4 Demo Mode Demo Mode Swith (0:Demo0,1:Demo1...) 0 - 7 0
5 Area Big Chg 0 - 4095 67
6 Area Small Chg 0 - 4095 67
7 Area Chg Sens 0 - 4095 150
8 Show Mode 0: Normal, 1: Show1, 2:Show2 0 - 3 0
9 AI_Calc_Mode 0: 8bit, 1: new 12bit, 2 old 12bit 0 - 2 2
81 FINE FPGA - Color Management
0 Y Range 0 - 32 8
1 Hue Range 0 - 20 10
2 Gain Range 0 - 50 30
3 GM Min Slope Gamma Correction Mini Slope 0 - 10 3
4 GM Max Slope Gamma Correction Max Slope 10 - 30 18
5 GM Converse Gamma Correction Converse Points 1 - 5 3
6 Not used
7 Not used
8 COLM_GET_LIND_Y_ud No. Points 1 - 9 9
9 Not used
10 Not used
11 Same Hue 1 - 10 3
12 Cut UV Norm 0 - 64 5
13 Cur MinY 0 - 127 0
14 Cur MaxY 125 - 255 255
