Sanyo PLC-HF15000L Service Manual

-81-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
15 Conv Y 0 - 63 24
16 Same Y 0 - 127 64
17 WB Limit 0 0 - 255 4
18 WB Limit 1 0 - 255 40
19 WB Limit 2 0 - 255 41
20 WB Limit 3 0 - 255 41
21 WB Limit 4 0 - 255 41
22 WB Limit 8 0 - 255 41
23 WB Limit In 0 - 255 14
24
WB Linit Out
0 - 255 20
25 WB Limit PtFlg 0 - 1 1
82 FPGA - Ye Overlay TYPE-L TYPE-R * Panel Type
0 DEC_R R Subtraction 0 - 255 150 170
1 DEC_G G Subtraction 0 - 255 30 10
2 B_RATIO B Addition 0 - 255 15 15
3 SAT_SLOPE Saturation Overlay 0 - 255 71 71
4 R_SLOPE R Hue Overlay 0 - 255 70 70
5 G_SLOPE G Hue Overlay 0 - 255 77 77
6 LUM_MAX PC-Standard 0 - 255 255 255
7 LUM_MAX PC-Rear 0 - 255 160 160
8 LUM_MAX PC-Dynamic 0 - 255 255 255
9 LUM_MAX AV-Standard 0 - 255 160 160
10 LUM_MAX AV-Cinema 0 - 255 160 160
11 LUM_MAX AV-Dynamic 0 - 255 255 255
12 LU_MIN PC-Standard 0 - 255 0 0
13 LU_MIN PC-Rear 0 - 255 0 0
14 LU_MIN PC-Dynamic 0 - 255 0 0
15 LU_MIN AV-Standard 0 - 255 0 0
16 LU_MIN AV-Cinema 0 - 255 0 0
17 LU_MIN AV-Dynamic 0 - 255 0 0
18 YE_SENS 0 - 255 4
19 YE_TESTFLG 0 - 255 3
20 DAC_MAX Not used 0 - 255 255
21 DAC_MIN Not used 0 - 255 0
22 DAC_UseMin DAC Level at Power Off 0 - 255 0
23 YE_FX_VAL PC-Standard 0 - 255 60
24 YE_FX_VAL PC-Rear 0 - 255 60
25 YE_FX_VAL PC-Dynamic 0 - 255 60
26 YE_FX_VAL AV-Standard 0 - 255 60
27 YE_FX_VAL AV-Cinema 0 - 255 60
28 YE_FX_VAL AV-Dynamic 0 - 255 60
29 DAC_Range Max 0 - 255 255
30 DAC_Range Min 0 - 255 32
31 P_PWM_WIDTH 0 - 16383 600
32 DAC_LEVEL For Ye Auto 0 - 255 255
33 YE_APLUsed APL usage 0 - 255 20
34 YE_APLOff 0 - 255 0
35 YE_FIX_VAL_SW PC-Standard 0 - 1 1
36 YE_FIX_VAL_SW PC-Rear 0 - 1 1
37 YE_FIX_VAL_SW PC-Dynamic 0 - 1 1
38 YE_FIX_VAL_SW AV-Standard 0 - 1 1
39 YE_FIX_VAL_SW AV-Cinema 0 - 1 1
40 YE_FIX_VAL_SW AV-Dynamic 0 - 1 1
41 YE_APL_A0 0 - 127 30
42 YE_APL_A1 0 - 127 62
43 YE_APL_A2 0 - 127 75
44 YE_APL_A3 0 - 127 90
45 YE_APL_A4 0 - 127 100
46 YE_GAIN_A0 - 256 - 256 -20
47 YE_GAIN_A1 - 256 - 256 -12
48 YE_GAIN_A2 - 256 - 256 -4
49 YE_GAIN_A3 - 256 - 256 13
50 YE_GAIN_A4 - 256 - 256 30
51 YE_APL_B0 0 - 127 8
52 YE_APL_B1 0 - 127 19
53 YE_APL_B2 0 - 127 30
54 YE_APL_B3 0 - 127 38
55 YE_APL_B4 0 - 127 45
56 YE_GAIN_B0 - 256 - 256 20
