Sanyo PLC-HF15000L Service Manual

-91-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
72 COMPONENT/RGB SW 0: Disable 1: Enable 0 - 1 1
80 Destination Language Set at Shipping 0:English 1:Japanese 0 - 1 0
140 OFFSET ADD MODE
Offset Tem Add Mode Display
0: No Addition, 1: Addtion
- 0
141 OFFSET ADD CHNG Apply Offset Change when the data is set 10 0 - 10 0
142 OFFSET Offset Temp - 10
143 TIMES OF OFFSET CHANGE 0 - 255 0
144 TIMES OF OFFSET RESET 0 - 255 0
201 Option (Signal) Not Used
0 FrameLock Option
Frame Lock Setting
0: OFF for PC
1: OFF for AV
2: OFF
3: ON Depending on Input Frequency
4: ON Depending on Input Frequency
0 - 4 4
204 Simulation mode
0 Scaler Enable 0: Off, 1: On 0 - 1 0
205 Spread Spectrum
0 Enable 0 - 1 0
1 Spread Rate Default 41 0 - 82 41
2 Spread Frequency Default 0 0 - 2 0
220 Projector Error Log
0 Warning_Log_1 Latest Error log 0 - 32767 0
: : : : :
49 Warning_Log_50 50th Error log 0 - 32767 0
50 Warning_Log Reset Log is cleared when the value is set to 10. 0 ~ 10 0
235 Shutter
0 Power ON_OFF Motion Shutter Warm - up Operation (0: Yes, 1: No) 0 - 1 Initial: 1 / Shipping: 0
1 CMP_TRM Chattering Detecting Term 0 - 32767 7000
2 OUT_DLY_TRM Output Term 0 - 32767 15000
3 CMP_CHK_CNT Count of Information Sync 0 - 15 5
4 OPEN_DLY Open Output Delay 0 - 63 30
5 CLOSE_DLY Close Output Delay 0 - 63 30
6 Position Check Time Position Check Time 1 - 255 30
7 Stop Mode
Shutter Operation in Stop Mode
0:Free, 1:Brake
0 - 1 0
8 Enable Close Cmd
Shutter Close Command
0:Disable, 1:Enable
0 - 1 1
9 Speed Control 0 - 255 0
10 Shutter Management Upper Time 180 - 999 480
239 Illuminance Sensor
0 Illuminance Factory Data 4 Lamp, Normal, Ye:Auto 0 - 32767 15000
1 Illuminance Factory Data 4 Lamp, Normal, Ye:Off 0 - 32767 12450
2 Illuminance Factory Data 4 Lamp, Eco, Ye:Auto 0 - 32767 11250
3 Illuminance Factory Data 4 Lamp, Eco, Ye:Off 0 - 32767 9338
4 Illuminance Model Data 4 Lamp, Normal, Ye:Auto 0 - 32767 1861
5 Illuminance Model Data 4 Lamp, Normal, Ye:Off 0 - 32767 1996
6 Illuminance Model Data 4 Lamp, Eco, Ye:Auto 0 - 32767 1325
7 Illuminance Model Data 4 Lamp, Eco, Ye:Off 0 - 32767 1433
-
10 Illuminance Factory Data 2 Lamp (1)(4), Normal, Ye:Auto 0 - 32767 7500
11 Illuminance Factory Data 2 Lamp (1)(4), Normal, Ye:Off 0 - 32767 6225
12 Illuminance Factory Data 2 Lamp (1)(4), Eco, Ye:Auto 0 - 32767 5625
13 Illuminance Factory Data 2 Lamp (1)(4), Eco, Ye:Off 0 - 32767 4669
14 Illuminance Model Data 2 Lamp (1)(4), Normal, Ye:Auto 0 - 32767 1005
15 Illuminance Model Data 2 Lamp (1)(4), Normal, Ye:Off 0 - 32767 1097
16 Illuminance Model Data 2 Lamp (1)(4), Eco, Ye:Auto 0 - 32767 727
17 Illuminance Model Data 2 Lamp (1)(4), Eco, Ye:Off 0 - 32767 784
-
20 Illuminance Factory Data 2 Lamp (2)(3), Normal, Ye:Auto 0 - 32767 7500
21 Illuminance Factory Data 2 Lamp (2)(3), Normal, Ye:Off 0 - 32767 6225
22 Illuminance Factory Data 2 Lamp (2)(3), Eco, Ye:Auto 0 - 32767 5625
23 Illuminance Factory Data 2 Lamp (2)(3), Eco, Ye:Off 0 - 32767 4669
24 Illuminance Model Data 2 Lamp (2)(3), Normal, Ye:Auto 0 - 32767 826
25 Illuminance Model Data 2 Lamp (2)(3), Normal, Ye:Off 0 - 32767 895
26 Illuminance Model Data 2 Lamp (2)(3), Eco, Ye:Auto 0 - 32767 596
