-93-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
7 Flow Ideal Data 8 Flow Sensor Theory Value No.8 Corresponding to Fan Volt No.8 0 - 1023 1023
242 Flow Calib. Fan Volt (Not Memorized)
0 Flow Calib Fan Volt 1 Flow Sensor Calibration Fan Volt No.1 [V x10] 0 - 255 30*
1 Flow Calib Fan Volt 2 Flow Sensor Calibration Fan Volt No.2 [V x10] 0 - 255 46
2 Flow Calib Fan Volt 3 Flow Sensor Calibration Fan Volt No.3 [V x10] 0 - 255 61
3 Flow Calib Fan Volt 4 Flow Sensor Calibration Fan Volt No.4 [V x10] 0 - 255 84
4 Flow Calib Fan Volt 5 Flow Sensor Calibration Fan Volt No.5 [V x10] 0 - 255 100*
5 Flow Calib Fan Volt 6 Flow Sensor Calibration Fan Volt No.6 [V x10] 0 - 255 255
6 Flow Calib Fan Volt 7 Flow Sensor Calibration Fan Volt No.7 [V x10] 0 - 255 255
7 Flow Calib Fan Volt 8 Flow Sensor Calibration Fan Volt No.8 [V x10] 0 - 255 255
243 Flow Calib Effective Difference (Not Memorized)
0 Flow Calib Effective Diff 1 Flow Sensor Calibration Range Diff No.1 [ADC] 0 - 1023 160
1 Flow Calib Effective Diff 2 Flow Sensor Calibration Range Diff No.2 [ADC] 0 - 1023 160
2 Flow Calib Effective Diff 3 Flow Sensor Calibration Range Diff No.3 [ADC] 0 - 1023 175
3 Flow Calib Effective Diff 4 Flow Sensor Calibration Range Diff No.4 [ADC] 0 - 1023 185
4 Flow Calib Effective Diff 5 Flow Sensor Calibration Range Diff No.5 [ADC] 0 - 1023 190
5 Flow Calib Effective Diff 6 Flow Sensor Calibration Range Diff No.6 [ADC] 0 - 1023 1023
6 Flow Calib Effective Diff 7 Flow Sensor Calibration Range Diff No.7 [ADC] 0 - 1023 1023
7 Flow Calib Effective Diff 8 Flow Sensor Calibration Range Diff No.8 [ADC] 0 - 1023 1023
244 Flow Clog Threshold (Not Memorized )
0 Flow Clog Threshold 1 Flow Sensor Clogged Threshold No.1[ADC] 0 - 1023 200
1 Flow Clog Threshold 2 Flow Sensor Clogged Threshold No.2[ADC] 0 - 1023 220
2 Flow Clog Threshold 3 Flow Sensor Clogged Threshold No.3[ADC] 0 - 1023 250
3 Flow Clog Threshold 4 Flow Sensor Clogged Threshold No.4[ADC] 0 - 1023 280
4 Flow Clog Threshold 5 Flow Sensor Clogged Threshold No.5[ADC] 0 - 1023 300
5 Flow Clog Threshold 6 Flow Sensor Clogged Threshold No.6[ADC] 0 - 1023 1023
6 Flow Clog Threshold 7 Flow Sensor Clogged Threshold No.7[ADC] 0 - 1023 1023
7 Flow Clog Threshold 8 Flow Sensor Clogged Threshold No.8[ADC] 0 - 1023 1023
10 Flow Inlet Err Threshold 1 Flow Sensor Intake Err Threshold No.1 [ADC] 0 - 1023 300
11 Flow Inlet Err Threshold 1 Flow Sensor Intake Err Threshold No.1 [ADC] 0 - 1023 320
12 Flow Inlet Err Threshold 1 Flow Sensor Intake Err Threshold No.1 [ADC] 0 - 1023 360
13 Flow Inlet Err Threshold 1 Flow Sensor Intake Err Threshold No.1 [ADC] 0 - 1023 400
14 Flow Inlet Err Threshold 1 Flow Sensor Intake Err Threshold No.1 [ADC] 0 - 1023 400
15 Flow Inlet Err Threshold 1 Flow Sensor Intake Err Threshold No.1 [ADC] 0 - 1023 1023
16 Flow Inlet Err Threshold 1 Flow Sensor Intake Err Threshold No.1 [ADC] 0 - 1023 1023
17 Flow Inlet Err Threshold 1 Flow Sensor Intake Err Threshold No.1 [ADC] 0 - 1023 1023
245 Filter Roll
0 Scroll One Time Execute Filter Cleaning (1: Start cleaning once) 0 - 1 0
246 Flow Clog Monitor (Read only)
0 Real Flow Data Real Flow Data [ADC] (Read only) 0 - 1023 -
1 Ideal Flow Data Theory Flow Data (Read only) 0 - 1023 -
2 Flow Difference Data Flow Difference Data [ADC] (Read only) -1023 - 1023 -
3 Clog Detect Flow Difference Data Difference Data to judge the Filter Clogged [ADC] (Read only) 0 - 1023 -
4 Warn Detect Flow Difference Data
Difference Data to judge the Filter Clogged Warning [ADC] (Read
only)
0 - 1023 -
5 Press Add Data Add Data by Air Pressure (Read only) 0 - 1023 -
6 Filter Scroll Timer Timer for Filter Scroll [hour] (Read only) 0 - 32767 -
7 Air Inlet Err Difference Data Difference to judge the Intake Error 0 - 1023 -
249 Pressure Sensor
0 Pressure Monitor Pressure Sensor Value [ADC] (Read only) - -
1 Pressure Monitor Pressure Sensor Value with Compensate [ADC] (Read only) - -
2 Presss Offset Offset Value - 1023 - 1023 0
3 Press calib Effective Diff Effective Range [ADC] 0 -123 1023
4 Press Sensor Calibration Log
0: Executed & Normal Range (Read ony)
10: Out of Range Minimum
20: Out of Range Maximum
99: Not execute Calibration
- 99
250 Fan Voltage Adjustment
0 Fan 1 Min Adjust (DAC)
DAC Output for Fan Voltage adj.
Adjust Tolerance between DAC and Fan Volt.
*Lamp Mode: Eco
0 - 255 106
1 Fan 1 Max Adjust (DAC) 0 - 255 211
252 Fan Option
1 Safety Switch Safety Application use 0 - 8 0
