4 Operation and Configuration
76
S84-ex/S86-ex Operator Manual
INTERFACE AUTO SELECT
Enable or disable the interface auto detection.
• ENABLE: Automatically select the connected interface.
• DISABLE: The interface is selected based on the interface setting.
Note
The setting will be effective only when you power on the printer again.
INTERFACE SETTING
Set whether or not to perform the interface settings.
• YES: Enter the PORT SELECT screen.
• NO: Enter the IGNORE CR/LF screen.
PORT SELECT
Select the port used for the connected interface.
• DATA PORT: For receiving various SBPL commands and executing
print operations.
• SUB PORT: For monitoring the printer status and connecting to exter-
nal devices.
DATA PORT
Select the connected interface for use with the data port.
One of the following interfaces can be selected.
•USB
•LAN
• RS-232C
• IEEE1284
• Bluetooth
•WLAN
Note
• Bluetooth shows only when a Bluetooth adapter is connected.
• WLAN shows only if a WLAN unit is installed.
• You cannot select the interface that has already been set for the SUB
PORT.
• The setting will be effective only when you power on the printer again.
To Next Page
