4 Operation and Configuration
77
S84-ex/S86-ex Operator Manual
SUB PORT
Select the connected interface for use with the data port.
One of the following interfaces can be selected.
•USB
•LAN
• RS-232C
• IEEE1284
• Bluetooth
• WLAN
•NONE
Note
• Bluetooth shows only when a Bluetooth adapter is connected.
• WLAN shows only if a WLAN unit is installed.
• You cannot select the interface that has already been set for the DATA
PORT.
• The setting will be effective only when you power on the printer again.
IGNORE CR/LF
Ignore or acknowledge the CR/LF code of the received data.
• YES: Ignore the CR/LF code.
• NO: Do not ignore the CR/LF code.
Note
Shows only if the DATA PORT is selected.
IGNORE CAN/DLE
Ignore or acknowledge the CAN/DLE code of the received data.
• YES: Ignore the CAN/DLE code.
• NO: Do not ignore the CAN/DLE code.
Note
Shows only if PROTOCOL is set to STATUS4.
