4 Operation and Configuration
85
S84-ex/S86-ex Operator Manual
PROTOCOL
Set the communication protocol.
• STATUS3: When selected, the printer will proceed to the IGNORE CR/
LF screen.
• STATUS4: When selected, the printer will proceed to the STATUS
REPLY TIMING screen.
• STATUS5: When selected, the printer will proceed to the ITEM NO.
CHECK screen.
ITEM NO. CHECK
Set the item number check function.
• ENABLE: Enable the item number check function.
• DISABLE: Disable the item number check function.
Note
Shows only when PROTOCOL is set to STATUS5.
BCC CHECK
Set the BCC check function.
• ENABLE: Enable the BCC check function.
• DISABLE: Disable the BCC check function.
Note
Shows only when PROTOCOL is set to STATUS5.
STATUS REPLY TIMING
Set the timing for replying with the status information to the host.
• ENQ: Returns a status after receiving a Status Request (ENQ), which
has been sent from the host.
• CYCLE: Returns a status from the printer to the host at an interval of
500 ms.
Note
Shows only when PROTOCOL is set to STATUS4.
To Next Page
