Installation manual
HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 17 of 201
Version: 25F
• Parameter administration for expansion modules in the basic device
• Contact multiplication or contact rating increase by means of external contactors in
conjunction with integrated monitoring possible
• Comprehensive diagnostic functions integrated in the firmware
• Coded status indication via 7-segment display and status LEDs on front
• Multi-function button (Confirmation, Start, Reset) can be operated from the front
• Optional: Communication interface incl. memory card slot
o Standard and safe fieldbus protocols for communication with a higher-level
controller
o Safe cross-communication for the exchange of data between several basic
devices
(2)
o Safe remote IO communication for the exchange of data with distributed IO
systems
o Serial diagnostic bus "SD bus"
(2)
o See: Section 3.7.4 Optional universal communication interface
• Optional: Memory card slot (-MC)
• Mounting on DIN rail
• The mechanical layout of the PSC1-C-100 (-FBx
(1)
) is different to the figure. (See
mechanical data)
