schmersal PSC1 - Page 19

Installation manual
HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 19 of 201
Version: 25F
Environmental data
Temperature 0°C … +50°C operation
-
25C° … +70C° storage, transport
Degree of protection
IP 20
Climatic class
3k3 according to DIN 60
721
-
3
Minimum, maximum relative humidity
(no condensation)
5% - 85%
EMC EN 61000-6-2, EN 61000-6-4, EN 61000-6-7,
EN 61800
-
3, EN 61326
-
3, EN 62061
Use of operating equipment
2000m
Overvoltage category
III
Level of contamination
2
Mechanical data
Size (HxDxW [mm]) PSC1-C-100 = 100x115x90
PSC1
-
C
-
100
-
(FBx
(1)
/MC)
= 100x115x112.5
Weight PSC1-C-100 = 530 g
PSC1
-
C
-
100
-
FBx
(1)
/MC
= 630 g
Attachment
Can be snapped to DIN rail
Number of T
-
bus connectors
Included in the
scope of delivery
PSC1
-
C
-
100
4
PSC1
-
C
-
100
-
FBx
(1)
/MC
5
Min. connection cross
-
section / IL
0.2 mm² / 24
Max. connection cross
-
section / IL
2.5mm² / 12
Options:
(*)
Of these maximum 6 axis modules
(**)
pn/pp can be configured via SafePLC2
(***)
Derating, see section "Derating of outputs"
(1)
For version see: “Optional universal communication interface"
(2)
on request
