Mechanical data
Size (HxDxW [mm]) PSC1-E-131 = 100x115x45
PSC1
-
E
-
133
= 100x115x67.5
Weight PSC1-E-131 = 300 g
PSC1
-
E
-
133
= 400 g
Attachment
Can be snapped to DIN
rail
Number of T
-
bus connector
Included in the
scope of delivery
PSC1
-
E
-
131
2
PSC1
-
E
-
133
3
Min. connection cross
-
section / IL
0.2 mm² / 24
Max. connection cross
-
section / IL
2.5 mm² / 12
Options:
***
Derating, see section "Derating of outputs"
1)
Value only applies for expansion module. For an overall assessment according to EN 13849
a series connection with the related basic device is to be used
=> PFH
Logic
= PFH
Basic
+ PFH
Expansion
