18 Mega-800 SCINCO
Chapter 3 Photometric measurement
3.1 Gain access to photometric mode
On the instrument main menu, please press to gain access to photometric mode. Press
to return to the instrument main menu, as shown in Fig. 3.1:
A: Main menu B: Photometric mode
Fig. 3.1Gain access to photometric mode
When you exit photometric mode, it will display “Delete all the data? (Yes: enter. No: CLE.)”. Press
, it will return to the instrument main menu and the measurement data will be lost. Press , it
will return to the photometric mode, and prompt the user with ―press START to measure‖, then the
user can continue on photometric measurement.
The following paragraphs introduce the main menu of photometric mode:
Fig. 3.2 Photometric mode
① “PHOTO”here means photometric measurement；“990 nm” is the current working
wavelength；“0.000 Abs”is the real-time Abs.
② Working area: display the detailed measurement data in the form of table. It can display
maximum 9 groups of values each screen, if exceeds, it will display on the next screens.
③ Information indicating area: the current information is prompting the user to press
Note:
Please print out the measurement data before returning to the instrument main menu, otherwise,
the data will be lost.
