74 Mega-800 SCINCO
changer is used to explain the replacing method. 5-cell changer and solid sample cell holder etc. can
be replaced with the same method.
Open the sample compartment, and remove the front baffle, as shown in Fig. 11.1.
Fig. 10.1 Remove the front baffle
Loosen the two holding screws by using the plus screwdriver, and remove the solid sample cell holder.
Fig. 10.2 Remove the solid sample cell holder
Put the plug of the 8-cell changer into the socket on the pedestal of the sample compartment, as
shown in Fig. 11.3.
Fig. 10.3 Put the plug of 8-cell changer into the socket
Position the 8-cell changer, fasten the two holding screws, install the front baffle, and cover the
sample compartment, as shown in Fig. 11.4.
