Servomex SERVOPRO MultiExact User Manual

MultiExact Gas Analyser 1 – Description and definitions
A.
B.
Analyser with external filters
Analyser with flowmeters
Key
Description
Key
Description
1. Display
2. Sample 2 gas label
3. Sample 1 gas label
4. Sample 2 external filter *
5. Sample 1 external filter *
6. Soft key 4
7. Soft key 3
8. Fault LED
9. Soft key 2
10. Alarm LED
11. Soft key 1
12. Sample 2 bypass flowmeter
†
13. Sample 2 flowmeter
14. Sample 1 bypass flowmeter
†
15. Sample 1 flowmeter
* TCD, O
2
purity and O
2
control transducers only.
†
Pressure-driven transducers only.
Figure 1 – Front of the analyser
A
SERVOMEX
SERVO
PRO
MultiExact Serial No. 05410/P0001
SERVOMEX
FILTERFILTER
Bypass
Sample
SERVO
PRO
MultiExact Serial No. 05410/P0001
SERVOMEX
1 2 3 4 5
1011 9 8 7 6
1 2 3 12 13 14 15
1011 9 8
7
6
B
DA/1142/C
Bypass
Sample
05410001A / Revision 6 3
