4
Installation
Terminal assignment
Operating Instructions – MOVIDRIVE
®
modular
123
4.12 Terminal assignment
INFORMATION
Reference potentials inside the device:
The device internal reference potential is designated as GND in the following table.
All reference potentials GND are internally connected to PE.
INFORMATION
The assignment "reserved" means that no cable must be connected to this connec-
tion.
INFORMATION
The technical data for the connection of power electronics and control electronics are
listed in chapter "Technical Data"(→2211).
24748536/EN – 11/2017
