SEW-Eurodrive MOVIDRIVE MDA90A-0640-503-X-S00

8
Technical Data
Technical data for MDA and MDD axis modules
Operating Instructions – MOVIDRIVE
®
modular
215
8.4 Technical data for MDA and MDD axis modules
8.4.1 MDA performance data
MOVIDRIVE
®
modular Unit MDA90A-...-503-X-...
Type 0020 0040 0080 0120 0160 0240 0320 0480 0640 1000 1400 1800
Size 1 2 3 5 6
Nominal output current I
N
PWM = 4kHz
A 2 4 8 12 16 24 32 48 64 100 140 180
Input
Nominal DC link voltage V
NDCL
DC560 V
Nominal DC link current I
NDCL
1)
A 2 4 8 12 16 24 32 48 64 100 140 180
Connection for UZ-/UZ+
CU bars
Screw M6×16 Screw M8×20
PE connection Screw M6×16
Motor output
Output voltage V
out
V 0 – max. V
line
Motor power ASM P
Mot
kW 0.6 1.5 4 5.5 7.5 11 15 22 30 45 75 90
Nominal output current I
N
PWM=4kHz
A 2 4 8 12 16 24 32 48 64 100 140 180
Max. output current at
f = 0 Hz
A 125% × I
N
: 1s at PWM = 4 kHz
Overload capacity 250%: 1s with PWM 4 kHz 200%: 3s with
PWM 4kHz
Apparent output power S
N
2)
kVA 1.4 2.8 5.5 8.5 11 17 22 33 44 69
PWM frequency f
PWM
kHz 4, 8, 16 (adjustable) 2.5, 4, 8 (ad-
justable)
Max. output frequency f
max
V/f: 599 Hz
VFC
PLUS
: 250 Hz
CFC: 500 Hz
ELSM
®
: 500 Hz
X2 connection
Plug connector
- 1 core: 0.25–4 mm
2
- 2 cores: 0.25–2.5 mm
2
(Twin-AEH)
3)
Plug con-
nector
- 1 core:
0.5–16 mm
2
- 2 cores:
0.25–6 mm
2
(Twin-AEH)
2)
M6 bolt
Max. 16mm
2
M10 screw
Max. 70mm
2
or
2 × 25 mm
2
M10 screw
Max. 120mm
2
PE connection
Screw M6×16 Screw M6×18
Screw
M10×25
Brake output
Nominal brake voltage V
BR
(DB00)
DC 24V, the tolerance depends on the DC 24V supply
X10 connection
Plug connector
- 1 core: 0.25–2.5 mm
2
- 2 cores: 0.5–1 mm
2
(Twin-AEH)
2)
General
Nominal power loss 24V W 20 22 25 30 75 115
Nominal power loss power sec-
tion
W 15 35 65 90 110 185 240 360 430 670 980 1250
Mass kg 4 4.1 5.3 7.1 14 18
Dimensions
Width mm 60 90 150 210 300
Height mm 328 428
Depth mm 265
1) The nominal DC link current is defined for cosφ = 0.82
2) In relation to PWM = 4 kHz
3) AEH: Conductor end sleeve
