Technical Data
Technical data of MDP power supply modules
Operating Instructions – MOVIDRIVE
®
modular
214
8.3.2 Electronics data – signal terminals
MDP.. power supply module Terminal General electronics data
DC 24V voltage supply X5 DC 24 V -10%, +20% according to EN61131
Cross section and contacts X5 Copper busbar, M4 × 12
Evaluation of temperature sensor at braking resistor
X7.1 DC 24V auxiliary voltage output to supply X7:2
X7.2 Sensor input for temperature monitoring of the braking resistor.
• Signal contact closes: No overtemperature.
• Signal contact open: Overtemperature.
Connect isolated signal contacts only.
X7.3/4 Reserved
Connection
Plug connector
- 1 core: 0.25–0.5 mm
2
