6
Operation
Axis module fault
Operating Instructions – MOVIDRIVE
®
modular
196
Subfault: 32.6
Description: Copy parameter set
Response: Output stage inhibit
Cause Measure
Error while downloading parameter set to device – Check the wiring of system bus and module bus.
– Restart download.
Subfault: 32.7
Description: Application heartbeat timeout
Response: Application heartbeat – timeout response
Cause Measure
Communication interrupted between IEC program in MOVI-C
®
CONTROLLER and device.
– Check the status of IEC program.
– Restart IEC program.
Subfault: 32.12
Description: Manual mode timeout
Response: Manual mode – timeout response
Cause Measure
Communication connection to device interrupted in manual
mode
– Check whether too many programs are open on the operator
PC.
– Increase the timeout time in manual mode.
New scope project created – Reset error.
– Restart the manual mode.
Scope measurement loaded from device – Reset error.
– Restart the manual mode.
6.5.27 Error 33 System initialization
Subfault: 33.1
Description: Motor current measurement
Response: Output stage inhibit
System state: Fault ackn.with CPU reset
Cause Measure
Motor current measurement detected error Contact the SEW-EURODRIVE Service.
Subfault: 33.2
Description: Firmware CRC check
Response: Output stage inhibit
System state: Fault ackn.with CPU reset
Cause Measure
Error while checking firmware Contact the SEW-EURODRIVE Service.
Subfault: 33.6
Description: FPGA configuration
Response: Output stage inhibit
Cause Measure
Error while checking FPGA configuration Contact the SEW-EURODRIVE Service.
Subfault: 33.7
Description: Function block compatibility error
Response: Output stage inhibit
Cause Measure
Error while checking compatibility of function block Contact the SEW-EURODRIVE Service.
Subfault: 33.8
Description: SW function block configuration
Response: Output stage inhibit
Cause Measure
Error detected while checking configuration of software function
block.
Contact the SEW-EURODRIVE Service.
24748536/EN – 11/2017
