4
Installation
Installation accessories
Operating Instructions – MOVIDRIVE
®
modular
49
4 Installation
MOVIDRIVE
®
modular application inverters are exclusively suitable for control cabinet
installation according to the degree of protection.
4.1 Installation accessories
4.1.1 Standard accessories
The listed standard accessories are included in the scope of delivery.
Standard accessories – mechanical accessories
Designation Power supply module Single-axis module Double-axis module Master
module
MDP90A- MDA90A- MDD90A- MDM90A
0100
(BG1)
0100
(BG1A)
0250 0500,
0750
0020,
0040,
0080,
0120
0160,
0240
0320,
0480
0640,
1000
0020,
0040
0020,
0040,
0080
Electronics shield
clamp
1×
Designation Power supply module Single-axis module Double-axis module
MDP90A- MDA90A- MDD90A-
0100
(BG1)
0100
(BG1A)
0250 0500,
0750
0020,
0040,
0080,
0120
0160,
0240
0320,
0480
0640,
1000
0020, 0040 0020,
0040, 0080
Power shield clamp 1×
The mechanical accessories can be ordered with the following part numbers:
Module Part number accessory pack
MDP90A.- power supply module
0100 (BG1): 28223756
0100 (BG1A): 28225198
0250: 28224507
0500, 0750: 28232984
Single-axis module MDA90A- 0020, 0040, 0080, 0120: 28223756
0160, 0240: 28233530
0320, 0480: 28220714
0640: 28226151
1000: 28231635
MDD90A- double-axis module
0020, 0040 (BG1): 28223756
0020, 0040, 0080 (BG2): 28220455
Master module UHX45A/MDM90A 28244389
24748536/EN – 11/2017
