4.7.3 CES11A multi-encoder card
INFORMATION
Technical data of the cards
For technical data and a detailed description of the encoder interface, refer to chapter
"Technical data of the cards".
Overview of functions
The CES11A multi-encoder card expands the functionality of the application inverter in
a way that an additional encoder can be evaluated. The encoder connected to the
CES11A multi-encoder card can be used as motor encoder or external encoder.
Supported encoder types
The following encoder types can be evaluated by the CES11A multi-encoder card:
HTL 12/24V (differential)
TTL (differential)
RS422
SIN/COS 1 V
SS
(differential)
HIPERFACE
®
with SIN/COS signals 1 V
SS
SEW encoder (RS485) with SIN/COS signals 1 V
SS
, e.g. AS7W, AG7W
EnDat 2.1 with SIN/COS signals 1 V
SS
SSI encoder with/without SIN/COS signals 1 V
SS
CANopen encoder
Resolvers cannot be evaluated with the CES11A multi-encoder card.
Encoder connection/cable lengths
Connection/Encoder Cable length
HTL encoder ES7C and EG7C 300m
Standard HTL encoder 200 m
Other encoders 100 m
INFORMATION
The maximum cable length might be reduced depending on the technical data of the
respective encoder. Observe the manufacturer specifications.
