Technical Data
Technical data of the master module UHX45A/MDM90A
Operating Instructions – MOVIDRIVE
®
modular
220
8.5 Technical data of the master module UHX45A/MDM90A
MOVIDRIVE
®
modular Terminal UHX45A/MDM90A
Input
DC 24V supply
1)
X5_A
40 A
Connecting contacts
2-pole plug connector
• 1 core: 0.5 – 10 mm
2
• 2 core: 0.5 – 6 mm
2
Output
DC 24V voltage output UHX45A
2)
X5_B
Maximum 40A
Fuse for voltage output UHX45A 5 × 20, 4A, 125V, miniature fuse, slow-blow
Part number: 18190464
DC 24V connection Maximum 40A
General
Power loss UHX45A 12 W
Mass 1.85 kg
Dimensions
Width 60
Height 383
Depth 250
1) The master module can be used to supply the DC 24V supply voltage for the entire axis system
2) Auxiliary output X5_B for supply of MOVI-C® CONTROLLER advanced UHX45A
24748536/EN – 11/2017
