6
Operation
Axis module fault
Operating Instructions – MOVIDRIVE
®
modular
200
6.5.32 Fault 47 Supply unit
Subfault: 47.1
Description: Supply unit – warning
Response: Warning with self reset
Cause Measure
The supply unit signals a fault with response type "warning".
The fault is only displayed.
Subfault: 47.2
Description: Supply unit – standard fault
Response: Emergency stop + output stage inhibit
Cause Measure
The supply unit signals a fault with response type "standard".
The axis performs a fault response that is determined by the
driver for the supply unit implemented on the axis.
Subfault: 47.3
Description: Supply unit – critical fault
Response: Output stage inhibit
Cause Measure
The supply unit signals a fault with response type "critical
error". The axis performs a fault response that is determined by
the driver for the supply unit implemented on the axis.
6.5.33 Error 48 Module bus
Subfault: 48.1
Description: Incompatible
Response: Output stage inhibit
Cause Measure
Module bus slave and module bus master not compatible
Subfault: 48.2
Description: Timeout
Response: Emergency stop + output stage inhibit
Cause Measure
Timeout detected by module bus. Check cable connections and voltage supply of module bus
stations.
6.5.34 Fault 50 I/O card
Subfault: 50.1
Description: Boot synchronization timeout
Response: Output stage inhibit
Cause Measure
Card is plugged in device but cannot be addressed. – Check device assignment of basic device and option.
– Check card slot and installation and correct if necessary.
– Restart device.
Subfault: 50.2
Description: CRC error of FPGA driver
Response: Output stage inhibit
Cause Measure
Communication between FPGA and option card does not work,
or is interrupted.
Check the card slot and installation and correct if necessary.
– Check for EMC-compliant installation.
– Restart device.
Subfault: 50.3
Description: CRC fault of option card
Response: Output stage inhibit
Cause Measure
Option card signals CRC error on SPI bus Check the card slot and installation and correct if necessary.
– Check for EMC-compliant installation.
– Restart device.
24748536/EN – 11/2017
