3 Unit structure, axis system structure
3.1 Connection variants
The MOVIDRIVE
®
modular application inverter can be used in the following connec-
tion variants:
• As axis system in connection with a MOVI-C
®
CONTROLLER power/power eco
• As axis system in connection with a master module UHX45A/MDM90A
• As axis system in connection with a MOVI-C
®
CONTROLLER advanced
• As axis system in connection with a MOVI-C
®
CONTROLLER standard
In one axis system, up to 15 axis modules can be used, both as single-axis modules
and double-axis modules.
NOTICE
Damage to the MOVIDRIVE
®
modular application inverter when opening the DC link
(separate operation).
Separate operation of individual modules will damage the application inverter and is
not permitted.
Only operate the application inverter when installed in a system as illustrated above.
