8
Technical Data
Technical data of braking resistors, filters and chokes
Operating Instructions – MOVIDRIVE
®
modular
243
8.9.2 TCB thermal circuit breaker option
General
The TCB thermal circuit breaker protects the braking resistor from constant overload
and protects in case of a short circuit in the cable or the braking resistor.
The setting range of the thermal circuit breaker has to be selected in such a way that it
corresponds to the tripping current I
F
of the braking resistor.
The switch reacts to the following events:
• Thermal overload via current monitoring device.
• Short circuit.
In the event of a fault, the thermal circuit breaker switches off the braking resistor. The
present fault is signaled via isolated NO and NC contacts.
After fault elimination, the thermal circuit breaker can be reconnected like a normal
miniature circuit breaker.
The thermal circuit breaker is installed on DIN rails (TS35).
UL and cUL approval
The thermal circuit breaker has the cRUus approval, independent of the application in-
verter.
Technical data
Circuit breaker type Unit TCB0040 TCB0063 TCB0100
Part number 19170424 19170432 19170440
Setting range A 2.5 – 4 4 – 6.3 6.3 – 10
Connection cross section main contact mm
2
1.5 – 16
Tightening torque Nm 2.5
Signal contact connection cross section mm
2
0.5 – 1.5
Tightening torque Nm 0.8
Mechanical service life 20000 switching cycles
Circuit breaker type Unit TCB0160 TCB0200 TCB0250 TCB0320 TCB0400
Part number 19170459 19148658 19170467 19170475 19170483
Setting range A 10 – 16 16 – 20 20 – 25 25 – 32 32 – 40
Connection cross section main contact mm
2
2.5 – 16 4 – 16 6 – 16 10 – 16
Tightening torque Nm 2.5
Signal contact connection cross section mm
2
0.5 – 1.5
Tightening torque Nm 0.8
Mechanical service life 20000 switching cycles
24748536/EN – 11/2017
