4
Installation
Wiring diagrams
Operating Instructions – MOVIDRIVE
®
modular
135
4.13 Wiring diagrams
4.13.1 General information on the wiring diagrams
• For technical data of the power electronics and the control electronics, refer to
chapter Technical data.
• For the terminal assignment and connections, refer to chapter "Terminal assign-
ment"(→2123).
4.13.2 Power connection
NOTICE
Incorrectly placed components.
Destruction of the power supply module.
• Do not install any other components between the line filter and the power supply
module.
NOTICE
Overtemperature of line filter and line choke.
Destruction of line filter and line choke.
• Make sure line filter and line choke are not heated by warm exhaust air of other
devices.
24748536/EN – 11/2017
