Installation

Control cabinet installation

Operating Instructions – MOVIDRIVE

modular

4.5.5 Removing the touch guards

[1]

[2]

20918971659

1. Remove the screws [1] of the touch guards of all modules.

2. Remove the touch guards [2] from all modules.

24748536/EN – 11/2017
