Technical Data
Technical data for MDA and MDD axis modules
Operating Instructions – MOVIDRIVE
®
modular
216
8.4.2 MDD performance data
MOVIDRIVE
®
modular Unit MDD90A-...-503-X-... MDD90A-...-503-X-...
With card slot
Type 0020 0040 0020 0040 0080
Size 1 2
Nominal output current I
N
PWM=4kHz A 2 × 2 2 × 4 2 × 2 2 × 4 2 × 8
Input
Nominal DC link voltage V
NDCL
DC560 V
Nominal DC link current I
NDCL
1)
A 4 8 4 8 16
Connection for UZ-/UZ+ CU bars
Screw M6×16
PE connection Screw M6×16
Motor output
Output voltage V
out
V 0 – max. V
line
Motor power ASM P
Mot
kW 2 × 0.55 2 × 1.5 2 × 0.55 2 × 1.5 2 × 4
Nominal output current I
N
PWM=4kHz A 2 × 2 2 × 4 2 × 2 2 × 4 2 × 8
Max. output current at f = 0 Hz A 125% × I
N
: 1s at PWM = 4 kHz
Overload capacity 250%: 1s at PWM = 4 kHz
Apparent output power S
N
2)
kVA 2 × 1.4 2 × 2.8 2 × 1.4 2 × 2.8 2 × 5.5
PWM frequency f
PWM
kHz 4, 8 (adjustable)
Max. output frequency f
max
V/f: 599 Hz
VFC
PLUS
: 250 Hz
CFC: 500 Hz
ELSM
®
: 500 Hz
X2 connection
Plug connector
- 1 core: 0.25 – 4mm
2
- 2 cores: 0.25 – 2.5 mm
2
(Twin-AEH)
3)
PE connection
Brake output
Nominal brake voltage V
BR
(DB00) DC 24V, the tolerance depends on the DC 24V supply
X10 connection
Plug connector
- 1 core: 0.25–2.5 mm
2
- 2 cores: 0.5–1 mm
2
(Twin-AEH)
2)
General
Nominal power loss 24V W 20 25
Nominal power loss power section W 2 × 15 2 × 35 2 × 15 2 × 35 2 × 65
Mass kg 4 4.85
Dimensions
Width mm 60 90
Height mm 328
Depth mm 265
1) The nominal DC link current is defined for cosφ = 0.82
2) In relation to PWM = 4 kHz
3) AEH: Conductor end sleeve
