4
Installation
Information regarding UL
Operating Instructions – MOVIDRIVE
®
modular
152
4.14 Information regarding UL
INFORMATION
Due to UL requirements, the following chapter is always printed in English independ-
ent of the language of the documentation.
4.14.1 Field Wiring Power Terminals
• Use 60/75°C solid or stranded copper wire only sized at 14 AWG minimum. Suit-
able for 1 wire per terminal.
• For double-axis modules use wire size 12 - 14 AWG
• Tighten terminals to in-lbs (Nm) as follows
Tightening torque in-lbs (Nm)
MDP90A-...-
Power supply module
Line connection Braking resistor terminals
0100 (size 1) X1 4.4254 – 5.3105 (0.5 – 0.6) X3 4.4254 – 5.3105 (0.5 – 0.6)
0100 (size 1A) X1 4.4254 – 5.3105 (0.5 – 0.6) X3 4.4254 – 5.3105 (0.5 – 0.6)
0250 X1 23.552 – 35.403 (3.0 – 4.0) X3 23.552 – 35.403 (3.0 – 4.0)
MDA90A-...-
Single-axis module
Motor connection -
0020 – 0120 X2 4.4254 – 5.3105 (0.5 – 0.6) - -
0160 – 0240 X2 13.276 – 15.046 (1.5 – 1.7) - -
0320 – 0480 X2 23.552 – 35.403 (3.0 – 4.0 - -
MDD90A-...-
Double-axis module
Motor connection -
0020 – 0040 X2 4.4254 – 5.3105 (0.5 – 0.6) - -
0020 – 0080 X2 13.276 – 15.046 (1.5 – 1.7) - -
All modules
DC link connection PE connection
X4 23.552 – 35.403 (3.0 – 4.0 23.552 – 35.403 (3.0 – 4.0
4.14.2 Short Circuit Current Rating
Suitable for use on a circuit capable of delivering not more than
• 5000 rms symmetrical amperes when protected by fuses and circuit breakers as
described in the tables below.
• 1800 rms symmetrical amperes when protected by fuses, circuit breakers and
TypeE Combination Motor Controllers as described in the tables below.
Max. voltage is limited to 500 V.
24748536/EN – 11/2017
